10W-15W uv laser

The 532 green laser can finely mark the smooth surface of a medical bottle

The 532 green laser can finely mark the smooth surface of a medical bottle

Brand effect! Medical glass bottle customers directly order 532 green laser





The 532 green laser developed, produced and sold by RFH can be clearly marked on the smooth surface of the medical glass bottle. The effect is clear, not fuzzy, and not easy to be erased.



  • Laser Wavelength:

    532nm
  • Average Output Power :

    35W @50kHz
  • Pulse Width:

    <25ns @50kHz
  • Pulse Repetition Rate :

    10-200kHz
  • Spatial Mode:

    TEM00
  • Beam Quality (㎡) :

    <1.2
  • Beam Diameter:

    1.0±0.2mm Measured at window
  • Beam Full Divergence Angle :

    <1.2mrad
  • Beam Circularity:

    >90%
  • Pulse-To-Pulse Stability:

    <2% RMS/@30kHz
  • Average Power Stability :

    <3% RMS/8hr
  • Beam-Pointing Drift:

    <30μrad/℃
  • Polarization Ratio:

    >100:1
  • Polarization Orientation:

    Horizontal
  • Operating Temp. & RH:

    10℃ to 35℃ | <80%
  • Storage Temp. & RH:

    -20℃ to 65℃ | <90 %
  • Electricity Requirement :

    100-240VAC |50/60Hz | Single phase
  • Power Consumption:

    <5000W
  • Warranty :

    18months
  • Product Detail
  • Video

uv laser



The 532 green laser can finely mark the smooth surface of a medical bottle



The 532 green laser developed, produced and sold by RFH can be clearly marked on the smooth surface of the medical glass bottle. The effect is clear, not fuzzy, and not easy to be erased.



The green light laser belongs to the cold light source, the beam quality is high, and has no attenuation. The beam spot is uniform and compact, the light transmission is good, is very suitable for the glass bottle to mark finely. The effect is fine, the mark is clear and firm and pollution-free. It is suitable for the marking of pharmaceutical glass bottles.



Last week, received a pharmaceutical glass bottle production customer, Mr. Li. He said that he saw peers in the use of the RFH RFHLaser of laser, therefore, he contacted our company without hesitation.
