10W-15W uv laser

3W 5W 7W 10W Glass Plastic UV Laser Source Controlling System

The 3D Glass Plastic UV Laser Source Controlling System is a revolutionary new laser marking technology that is capable of marking glass and plastic surfaces with intricate detail and accuracy. This technology has the potential to revolutionize the way products are marked, allowing for the creation of complex 3D logos and designs with exceptional precision.



  • Laser Wavelength:

    354.7nm
  • Average Output Power :

    3W-10W @30kHz
  • Pulse Width:

    <12ns @ 30kHz
  • Pulse Repetition Rate :

    10-200kHz
  • Beam Quality (㎡) :

    <1.2
  • Beam Diameter :

    0.8±0.2mm Measured at window
  • Beam Full Divergence Angle :

    <2mrad
  • Beam Circularity :

    >90%
  • Pulse-to-Pulse Stability :

    <2% RMS/@30kHz
  • Average Power Stability :

    <5% RMS/8hr
  • Beam-Pointing Drift :

    <30μrad/℃
  • Polarization Ratio :

    >100:1
  • Polarization Orientation :

    Horizontal
  • Operating Temp. & RH :

    10℃ to 30℃ | <80%
  • Storage Temp. & RH) :

    -20℃ to 65℃ | <90 %
  • Electricity Requirement :

    100-240VAC |50/60Hz | Single phase
  • Power Consumption :

    <500W
  • Warranty :

    18months
  • Product Detail
  • Video

uv laser

The 3D Glass Plastic UV Laser Source Controlling System is a revolutionary new laser marking technology that is capable of marking glass and plastic surfaces with intricate detail and accuracy. This technology has the potential to revolutionize the way products are marked, allowing for the creation of complex 3D logos and designs with exceptional precision.

355nm uv laser mark white on black plastic charging socket

Using a 3D glass plastic UV laser Source Controlling System offers many advantages over traditional methods of marking. It is faster, more accurate, and can be used on a variety of materials. It is also more cost-effective and environmentally friendly than other marking methods.

UV Fiber Laser Device

Top China Brand UV laser source at 355 nm, with a pinpoint laser spot and the lowest heat-affected zone. It has a wide range of applications and is appropriate for high-precision marking down to 0.02 mm.

Cold laser prevents material burning or damage.

Saving money with a small, compact size, an integrated design without large optical components!

The UV laser marking machine’s major component is its one-of-a-kind low-power laser beam, which is particularly well suited for the high-end market of ultra-fine processing and is used to mark the surface of packaging bottles for cosmetics, medications, and other polymer materials.



The marking is crisp and solid, and the impression is satisfactory. Better than ink coding and pollution-free; flexible PCB board marking and dicing; silicon wafer micro-hole and blind-hole processing; LCD liquid crystal glass two-dimensional code marking; glassware surface drilling; metal surface coating marking; plastic buttons; electronic components; gifts; communication equipment; building materials, etc.
