10W-15W uv laser

RFH 355nm UV Laser 5 W for Silicone Marking or Cutting

RFH 355nm UV Laser 5W is a high-precision laser machine specially designed for silicone marking or cutting. Silicone materials have become increasingly popular in recent years due to their durability, flexibility, and resistance to extreme temperatures. With the RFH 355nm UV Laser 5W, you can now easily mark or cut these materials with great precision and accuracy.



  • Laser Wavelength:

    354.7nm
  • Average Output Power :

    10W/12W/15W @40kHz
  • Pulse Width:

    <20ns @40kHz
  • Pulse Repetition Rate :

    10-200kHz
  • Spatial Mode:

    TEM00
  • Beam Quality (㎡) :

    <1.2
  • Beam Diameter:

    0.8±0.1mm Measured at window
  • Beam Full Divergence Angle :

    <2mrad
  • Beam Circularity:

    >90%
  • Pulse-To-Pulse Stability:

    <3% RMS/@30kHz
  • Average Power Stability :

    <5% RMS/8hr
  • Beam-Pointing Drift:

    <25μrad/℃
  • Polarization Ratio:

    >100:1
  • Polarization Orientation:

    Horizontal
  • Operating Temp. & RH:

    10℃ to 35℃ | <80%
  • Storage Temp. & RH:

    10℃ to 35℃ | <90 %
  • Electricity Requirement :

    100-240VAC |50/60Hz | Single phase
  • Power Consumption:

    <800W
  • Warranty :

    18months
  • Product Detail
  • Video

uv laser

RFH 355nm UV Laser 5W is a high-precision laser machine specially designed for silicone marking or cutting. Silicone materials have become increasingly popular in recent years due to their durability, flexibility, and resistance to extreme temperatures. With the RFH 355nm UV Laser 5W, you can now easily mark or cut these materials with great precision and accuracy.

One of the key features of this laser machine is its high power and ultra-short pulse duration. This ensures that the laser beam is focused on a very small spot, which helps to achieve a high level of precision with the markings or cuts. The laser also has a high repetition rate, which means that it can work at a faster speed without compromising on precision.



Another important feature of the RFH 355nm UV Laser 5W is its stability and reliability. The laser is made from high-quality materials and components, which ensures that it can work continuously without any breakdowns. This is particularly important when it comes to marking or cutting silicone materials, which can be difficult to work with using conventional machinery.



In addition to its robust construction and high precision, the RFH 355nm UV Laser 5W is also very easy to use. The machine comes with a user-friendly interface that allows operators to input parameters and customize settings according to their needs. This makes it a great investment for businesses that require a high level of precision and accuracy in their operations.



Finally, the RFH 355nm UV Laser 5W is also environmentally friendly. It uses less energy than traditional laser machines, which means that it has a lower carbon footprint. This is an important consideration for businesses that are looking to reduce their environmental impact without compromising on quality.



In conclusion, the RFH 355nm UV Laser 5W is an excellent investment for businesses that require high-precision marking or cutting of silicone materials. It is easy to use, reliable, and environmentally friendly, making it a great choice for businesses that value quality, precision, and sustainability.
