10W-15W uv laser

RFH's 5W UV Laser Engraves Letters on Glass Bulbs

RFH's 5W UV laser adopts advanced laser technology, which can write various characters and patterns on the surface of glass bulbs. Compared with traditional lettering methods, UV laser lettering has the advantages of high precision, fast speed, and low loss.

  • Laser Wavelength:

    354.7nm
  • Average Output Power :

    3W-10W @30kHz
  • Pulse Width:

    <12ns @ 30kHz
  • Pulse Repetition Rate :

    10-200kHz
  • Beam Quality (㎡) :

    <1.2
  • Beam Diameter :

    0.8±0.2mm Measured at window
  • Beam Full Divergence Angle :

    <2mrad
  • Beam Circularity :

    >90%
  • Pulse-to-Pulse Stability :

    <2% RMS/@30kHz
  • Average Power Stability :

    <5% RMS/8hr
  • Beam-Pointing Drift :

    <30μrad/℃
  • Polarization Ratio :

    >100:1
  • Polarization Orientation :

    Horizontal
  • Operating Temp. & RH :

    10℃ to 30℃ | <80%
  • Storage Temp. & RH) :

    -20℃ to 65℃ | <90 %
  • Electricity Requirement :

    100-240VAC |50/60Hz | Single phase
  • Power Consumption :

    <500W
  • Warranty :

    18months
  • Product Detail
  • Video

uv laser

RFH's 5W UV Laser Engraves Letters on Glass LED bulb

bulb laser marking

RFH's 5W UV laser adopts advanced laser technology, which can write various characters and patterns on the surface of glass LED bulb. Compared with traditional lettering methods, UV laser lettering has the advantages of high precision, fast speed, and low loss.



The main difficulty in engraving text and patterns on glass LED bulb lies in the accuracy and speed of engraving. Traditional lettering methods usually use mechanical lettering or chemical etching, which are not only slow, but also easily damage the surface of the glass bulb. In contrast, RFH's 5W UV laser uses a high-precision laser beam to irradiate the surface of the glass bulb. By controlling the power and moving speed of the laser beam, it can write clear and fine text and patterns on the surface of the glass bulb.



In addition, UV laser inscription can also achieve fast inscription. Due to the high power of the ultraviolet laser beam, the writing operation can be completed in a short time, which improves the production efficiency. At the same time, the UV laser inscription will not affect other parts of the glass bulb, so the loss can be greatly reduced.



To sum up, RFH's 5W UV laser has great advantages in writing text and patterns on glass LED bulb. With the continuous development of laser technology, UV laser inscription will become one of the important technologies in the field of glass processing in the future.
